Xerox 5400

Last Updated on

In July 1977 Xerox introduced the copier/duplicator Xerox 5400. The 5400 was an advanced member of the 4000/4500 family. The 5400 could produce 45 copies in a minute, as was the same for the Xerox 4000 and 4500 copier. Actually, the 5400 had the same engine as theĀ 4000, 4500 and 5600, but with changes in development and drum cleaning.

The 5400 had brush development, a vacuum style drum cleaning system like a duplicator, a much more robust and heavy document handling system, and a microcontroller system control, much like the 9200 family. A sidecar on the left side of the 5400 housed the drive motors and support for the document handler and the collection box for the unused toner from the drum cleaning system.

SPECIFICATIONS
Copy speed (per minute)45. First copy after 7 seconds.
Paper tray1000 sheets. Two paper trays with 500 sheets each.
Output tray capacityn/a
Finisher/sorter20 bin sorter
Staple function
Reduction/zoom
Document handlerSEMI-automatic
Dimension and weight
Depth71 (cm) / 28 (inches)
Width117 (cm) / 45 (inches)
Height119 (cm) / 47 (inches)
Weight402 (K grams) / 886 (Lbs)
Floor space requirementsStationary: 2 x 2 (meter)/ 8 x 7 (feet)
Movable: 2 x 2 (meter) / 6 x 6 (feed)

Do you have any more information about this model, or have brochures / pictures? Please leave a reply in the form below, or send an email to xeroxnostalgia@outlook.com

Subscribe
Notify of
guest

This site uses Akismet to reduce spam. Learn how your comment data is processed.

3 Comments
Newest
Oldest Most Voted
Inline Feedbacks
View all comments
Jim Frieday
Jim Frieday
July 10, 2018 1:41 am

Another feature the 5400 had was bi-directional sorting. Unlike the 4500 that used a less than 8 switch (that would dead-cycle the machine until the sorter bins reset back to home) the 5400 delivered the copies as the bins move both up and down. This improved the output time of the copies.

Jim
Jim
September 22, 2015 3:39 am

Correction to above: they were prone to TONER explosions. Clouds of the highly volatile plastic-and-ink toner would accumulate and, set off by sparks or electrostatic discharge, detonate resulting in a loud BOOM and sometimes the cabinet doors blowing open or even completely off the hinges. I never heard of injury or property damage.

Jim
Jim
September 22, 2015 3:36 am

These guys were constructed with a heavy iron frame, and were built to last. They were pretty good when maintained properly. There was only one problem, which many of us considered hilarious: they were prone to tower explosions, causing the cabinet door to blow off! This happened in the White House causing a great deal of consternation. Veery early in Reagan;s first term, if I recall correctly. Friends of mine in the Federal Branch confirmed that this seemingly apocryphal event actually happened.
